Body
- Durable aluminum body with 360° rotation and 80° tilting.
LED Characteristics
- This general application light ?xture features a 9 watt LED module that maintains uniform intensity producing up to 875 lumens; with a typical CRI of 90. With a CCT range of 2700 K – 5000 K color temperature.
Dimming
- 100%-10% dimming capability. This ?xture is compatible with industry standard TRIAC/ELV dimmers.
- For compatible dimmers, visit www. liteline.com/Orbit
Beam Spread
- The ?xture lens provides 36° beam spread.
Mounting
- Includes two spring loaded clips to attach to any ceiling material.
LED Driver
- Extruded aluminum hardwire box with 210mA dimmable class II electronic LED driver with 100-135V, 60Hz AC input.
- Includes an 15″ FT6 rated cable with 3-pin DC connector between driver and ?xture approved for use in plenums and suspended ceilings.
- Includes 5 position CCT switch.
Quick Connect push-in terminals
- Three “Quick connect” push-in terminals for fast and easy wiring.
Operating Temperature
Environment
- Suitable for wet locations.
- Approved for direct contact with insulation.
- Airtight
- Indoor / Outdoor rated.
